Integrated Amplifier with MiND2 streamer and DSD DAC

MOON ACE
MOON ACE
MOON ACE
MOON ACE
MOON ACE
MOON ACE
MOON ACE
4.090,00 Price include 21% VAT Price exclude VAT € 3.380,17
AVAILABILITY1 DAY

Music Emotion
Alpha Audio
Hifi+
Audiostream
What Hifi
Audio
Stereo
The Audiophile Apartment
Trusted Reviews
Soundstage Hi-Fi
AV Forums
Hifi and Music Source
BBC Music
Eins Null
Audio Test


Experience
Featuring our MiND (MOON intelligent Network Device) module which provides convenience and a full graphic interface, allowing you to effortlessly access your digital music library with power and flexibility.

Intuitive
The ACE is both intuitive and easy to use. Bridging digital and analog audio at a price/performance ratio that is impossible to beat, the ACE includes a high resolution DAC with DSD decoding up to DSD256 and 32-bit/384kHz PCM.

Finest sounding
The finest sounding and most complete “all-in-one” available, the ACE can do virtually anything expected of a high-performance audio component of this nature. Accentuated by our world renowned MOON sonic signature – visceral tight bass, transparent midrange, precise natural highs – along with lifelike sound, plus countless features, the ACE will be the “heart and soul” of all your musical indulgences.

SimLink™
Of course, key features you’d expect in a MOON Nēo Series product are present such as SimLink™, RS-232 and IR ports for custom-install environments. At the other end of the audio spectrum, a moving magnet phono preamplifier rounds out this complete package.

Design features
- 3 line-level inputs including a front-mounted 1/8” mini-jack for personal media players.
- Headphone output on 1/4” jack located on the front panel.
- Seamless integration with our MiND app.
- 8 digital inputs include USB (hi-res audio), SPDIF (2), Optical (2), Qualcomm® aptXTM audio for
 Bluetooth®, WiFi and Ethernet.
- OLED type screen which provides more detailed information.
- Simple MiND setup via on-board software menu.
- Moving magnet phono preamplifier input.
- Analog inputs are configurable to “pass-through” mode, which bypasses the gain stage to
 accommodate components like a home-theater processor, whose own volume control is used.

Specifications
- Output Power at 8Ω: 50 W per channel
- Input Sensitivity: 370 mV - 3.0 V RMS
- Input Impedance: 22,1 kΩ
- Gain: 37 dB
- Signal-to-noise Ratio: 100 dB @ full power
- Frequency response (full range): 10 Hz - 80 kHz +0/-3 dB
- Crosstalk: -100 dB
- THD (20Hz - 20kHz @ 1 W / 50 W): 0.02 % / 0.02 %
- Intermodulation distortion: 0.005%
- PCM Bit-depth range / sampling rates: 16 - 32 bits / 44.1 - 384 kHz
- DSD sample rates: DSD64, DSD128 & DSD256
- Shipping weight: 29 lb / 13 kg
- Dimensions (width x height x depth): 42.9 x 8.9 x 36.6 cm
